The Titan Plenum Fan line is manufactured from high-strength 1020 carbon steel sheet and features a Plenum Fan-type impeller, with efficiency of up to 81%.
The equipment features dynamically balanced impellers, a reinforced belt guard, and IP54 protection rating, Class II protection (double insulation, no grounding required), and Class F insulation.
The line includes models in sizes from 200 to 1250, with larger options available upon request, airflow rates of up to 50,000 m³/h, and pressures of up to 400 mmWG. It also offers optional features and accessories for customization according to project requirements.
About the Product
Main Features
- Manufacturing material: high-strength 1020 carbon steel sheet;
- Design: Plenum Fan-type impeller;
- Efficiency of up to 81%;
- Dynamically balanced impellers;
- Reinforced belt guard;
- IP54 protection rating: resistance to dust and splashing water;
- Class II protection: double insulation, no grounding required;
- Class F insulation;
- Airflow rate of up to 50,000 m³/h;
- Pressure of up to 400 mmWG;
- Sizes from 200 to 1250, with larger models available upon request.
Optional Features and Accessories
Available for customization:
- Painted equipment;
- Bearing outside the airflow;
- Flexible connector;
- Vibration dampers;
- Protective screen at the air intake.
NOTE: The standard product is supplied without paint. Painting can be requested as an option.
Models
| MODEL | SIZE | ARRANGEMENT | CLASS | POSITIONS |
|---|---|---|---|---|
| Titan Plenum Fan | 200 a 1250 | 3 e 4 | I, II e III | Motor in positions W and Z |
